3M™ Double Coated Tape 9500PC, Clear, 3/4 in x 36 yd, 5.6 mil, 48 rolls per case
Stock : 7000123415
List:
$30.94
/Rolls
Your Price:
$23.57
/Rolls
- Buy 240 for $22.83 each and save 3%
- Buy 480 for $21.90 each and save 7%
Availability:
In stock
Ships In 7-10 Days
Quantity Guidelines:
Priced per Rolls s, must be ordered in multiples of 48.
Grand Total : $1,131.36
Manufacturer :
3M
SKU :
70006103009
Part :
67794
UPC :
021200677946
Selling Unit :
Rolls
Stock :
7000123415
3M™ Double Coated Tape 9500PC is a 5.6 mil 350 high performance acrylic adhesive double coat with polyester carrier on a 4.5 mil 61.5 lb polycoated kraft paper liner.
Excellent solvent resistance and adhesion to LSE materials. Up to 450 degrees F short-term heat resistance.
This broad line of tapes features pressure sensitive adhesive on front and back for bonding a wide variety of surfaces in many applications.
This broad line of tapes features pressure sensitive adhesive on front and back for bonding a wide variety of surfaces in many applications.
| Per Case | 48 rolls |
|---|---|
| Master Size Width | 48 Inch |
| Master Size Length | 360 Linear Yard |
| Maximum Operating Temperature (fahrenheit) | 350 Degree Fahrenheit |
| Nominal Tape Thickness (mils) W/o Liner | 5.6 Milli-inch (mil) |
| Moisture Resistance | High |
| Minimum Operating Temperature (fahrenheit) | -40 Degree Fahrenheit |
| Maxmum Operating Temperature (celsius) | 177 Degree Celsius |
| Uv Resistance | Medium |
| Type | simple |
| Total Thickness With Liner | 10.1 Milli-inch (mil) |
| Product Form | Roll |
| Primary Liner Thicknes (mils) | 4.5 Milli-inch (mil) |
| Primary Liner Color | Tan |
| Primary Liner | 61.5 Polycoated Kraft Paper |
| Plasticizer Resistance | Low |
| Restriction | Bulk |
| Solvent Resistance | 8 |
| Secondary Liner Thickness (mils) | >=0 Milli-inch (mil) |
| Humidty Resistance | 9 |
| Faceside Adhseive Thickness (mils) | 2.3 Milli-inch (mil) |
| Eu Rohs Compliant | Yes |
| Faceside Adhseive Type | 350 High Performance Acrylic |
| China Rohs Below Mcv | Yes |
| Carrier Material | Polyester |
| Carrier Thickness (mils) | 1 Milli-inch (mil) |
| Chemical Resistance | 8 |
| UPC 11 | 02120067794 |
| UPC Number | 021200677946 |
| Shear Strength At 72 Degrees F | 8 Pound-Force Per Square Inch |
| Length | 36 yd |
| Length Metric | 32.91 m |
| Width | 0.75 in |
| Width Metric | 19.05 mm |
| Benefit1 | |
| Benefit2 | High holding strength with short-term heat resistance up to 350F |
| Benefit3 | Provides moisture stability and the liner reduces edge burr during hard tool diecutting |
| Benefit4 | Electronics, General Industrial, Appliances, Medical Devices, Power Tools, Automotive, Transportation, Aircraft, Airplane |
| Benefit5 | Adhering, joining, affixing, bonding, mounting, holding, laminating, and attaching |
| Color 1 | Clear |
| Dimension 1 | 3/4 in |
| Dimension 2 | 36 yd |
| Adhesion To Foam | 9 |
| Adhesion To Hse | 10 |
| Adhesion To Lse | 10 |
| Adhesion To Metal | 9 |
| Adhesive Color | Clear |
| Adhesive Peel Ultimate | 9 |
| Backside Adhesive Thickness (mils) | 2.3 Milli-inch (mil) |
| Backside Adhesive Type | 350 High Performance Acrylic |
| TDS Files | 3M/tds/70070938553.pdf |
