3M™ Double Coated Tape 9420, Red, 1 in x 36 yd, 4 mil, 48 rolls per case
Stock : 7010372140
List:
$43.58
/Rolls
Your Price:
$33.21
/Rolls
- Buy 240 for $32.16 each and save 3%
- Buy 480 for $30.85 each and save 7%
Availability:
In stock
Ships In 7-10 Days
Quantity Guidelines:
Priced per Rolls s, must be ordered in multiples of 48.
Grand Total : $1,594.08
Manufacturer :
3M
SKU :
70006062361
Part :
16055
UPC :
021200160554
Selling Unit :
Rolls
Stock :
7010372140
3M™ Double Coated Tape 9420 is a 4.0 mil double coated polyester with red tinted acrylic adhesive 400 on a 3.5 mil 60 lb densified kraft paper liner
Good low temperature performance and peel strength on many surfaces. Up to 250 degrees F short-term heat resistance. Excellent adhesion to uncoated papers. Clarity and UV resistance for window label applications.
This broad line of tapes features pressure sensitive adhesive on front and back for bonding a wide variety of surfaces in many applications.
This broad line of tapes features pressure sensitive adhesive on front and back for bonding a wide variety of surfaces in many applications.
| Per Case | 36 rolls |
|---|---|
| Master Size Width | 48 Inch |
| Master Size Length | 108 Linear Yard |
| Liner Thickness | 4 Milli-inch (mil) |
| Liner Color | Tan |
| Maximum Operating Temperature (fahrenheit) | 180 Degree Fahrenheit |
| Nominal Adhesive Thickness (mils) | 4 Milli-inch (mil) |
| Moisture Resistance | 8 |
| Minimum Operating Temperature (fahrenheit) | -40 Degree Fahrenheit |
| Maxmum Operating Temperature (celsius) | 82 Degree Celsius |
| Tape Type | Double Coated |
| Uv Resistance | High |
| Type | simple |
| Total Thickness | 8 Milli-inch (mil) |
| Tape Thickness | 4 Milli-inch (mil) |
| Product Form | Roll |
| Primary Liner Thicknes (mils) | 4 Milli-inch (mil) |
| Primary Liner | 60 Densified Kraft Paper |
| Plasticizer Resistance | Low |
| Restriction | Bulk |
| Secondary Liner | Not Applicable |
| Solvent Resistance | 5 |
| Humidty Resistance | 8 |
| Faceside Adhseive Thickness (mils) | 1.5 Milli-inch (mil) |
| Eu Rohs Compliant | Yes |
| Faceside Adhseive Type | 400 High-Tack Acrylic |
| China Rohs Below Mcv | Yes |
| Carrier Material | Polyester |
| Carrier Thickness (mils) | 1 Milli-inch (mil) |
| Chemical Resistance | 5 |
| UPC 11 | 02120016055 |
| Liner Type | 60 Densified Kraft |
| UPC Number | 021200160554 |
| Shear Strength At 72 Degrees F | 5 Pound-Force Per Square Inch |
| Color | Red |
| Thickness | 8 mil |
| Length | 36 yd |
| Length Metric | 32.91 m |
| Thickness Metric | 0.2 mm |
| Width | 1 in |
| Width Metric | 25.4 mm |
| Benefit1 | |
| Benefit2 | Excellent UV resistance. Good adhesion to a wide variety of materials such as HSE high surface energy, LSE low surface energy and metals. Good temperature and humidity resistance. |
| Benefit3 | High performance splicing in printing applications. Good on films and foils. |
| Benefit4 | Paper and Print, Commercial Printing |
| Benefit5 | Used for flying splices on paper and film where easy visibility for removal of spliced area is desirable. |
| Color 1 | Red |
| Dimension 1 | 1 in |
| Dimension 2 | 36 yd |
| Adhesion To Foam | 5 |
| Adhesion To Hse | 5 |
| Adhesion To Lse | 5 |
| Adhesion To Metal | 5 |
| Adhesive Peel Ultimate | 5 |
| Adhesive Thickness (mils) | 4 Milli-inch (mil) |
| Adhesive Type | 400 High-Tack Acrylic |
| Backside Adhesive Thickness (mils) | 1.5 Milli-inch (mil) |
| Backside Adhesive Type | 400 High-Tack Acrylic |
| TDS Files | 3M/tds/70070938504.pdf |
